Product name: Ohaus MB
Modal: 23
Draftshield: Yes
Readability : 0.01g
Ohaus MB 23
MOISTURE ANALYZERS
| Maximum Capacity | 110 g |
| Readability Moisture Content | 10 mg/0.1% |
| Pan Size | 3.5 in (90 mm) |
Outstanding Performance, Flexible Configuration and Reliable Results.
The MB23 provides precise moisture content determination at an unbeatable value. With a large backlit LCD display, standard RS232 port, 110g capacity with a readability of 0.01g/0.1% and an non-glass infrared heating element, the MB23 offers moisture analysis for any budget.
Applications
Percent Moisture Determination, Percent Solid Determination, Weighing
Display
Backlit liquid crystal display (LCD)
Operation
Power cord (included)
Communication
RS232 (included)
Construction
Infrared heat source, ABS housing, metal pan support, metal pan handler, in-use cover
Design Features
3 shut off criteria (manual, timed or auto), 1 standard heating profile, 50° to 160° C heating range (5° C increments)
Specifications
Model:
MB23
Capacity:
110g
Repeatability:
0.3% (3g sample), 0.2% (10g sample)
Readability:
0.1% / 0.01g
Sample Size:
3g to 20g typical, 0.5g min
Interface:
Bidirectional RS-232 Timer: 1 – 99 minutes, 30-second increments to 60 minutes
Heating Technology:
Infrared (no glass)
Temperature Range:
50°C to 160°C in 5° increments
Power:
100 to 240 VAC, 50/60 Hz
Tare Range:
To capacity by subtraction
Operating Temperature Range:
5° to 40°C
Display Type:
Custom backlit LCD
Displays:
% moisture or % solids or weight (g), temperature,
time Pan Size (Diameter):
90 mm
Dimensions (W x H x D):
17 x 13 x 28 cm
Net Weight:
2.3 kg
Shipping Weight:
3.9 kg
Included Accessories:
Sample Pans (Quantity 50): Standard
In Use Cover: Standard
Sample Pan Handler: Optional (PN 11113873)
Models are CE, CSA/UL and FCC approved
